General information |
Model |
Harley-Davidson CVO Limited |
Year |
2017 |
Category |
Touring |
Engine and transmission |
Displacement |
1868.0 ccm (113.99 cubic inches) |
Engine type |
V2, four-stroke |
Engine details |
Twin-Cooled™ Milwaukee-Eight™ 114 |
Power |
102.0 HP (74.5 kW)) @ 5250 RPM |
Torque |
165.0 Nm (16.8 kgf-m or 121.7 ft.lbs) @ 3250 RPM |
Compression |
10.5:1 |
Bore x stroke |
102.0 x 114.5 mm (4.0 x 4.5 inches) |
Fuel system |
Injection. Electronic Sequential Port Fuel Injection |
Lubrication system |
Dry sump |
Cooling system |
Oil & air |
Gearbox |
6-speed |
Transmission type |
Belt (final drive) |
Clutch |
Multi-plate with diaphragm spring in oil bath |
Driveline |
Chain, 34/46 ratio primary drive |
Fuel consumption |
5.50 litres/100 km (18.2 km/l or 42.77 mpg) |
Greenhouse gases |
127.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
Exhaust system |
Chrome dual exhaust with 4 inch touring mufflers and touring muffler shields |
Chassis, suspension, brakes and wheels |
Rake (fork angle) |
26.0° |
Trail |
170 mm (6.7 inches) |
Front suspension |
Telescopic fork |
Rear suspension |
Twin shocks |
Front tire |
130/80-B17 |
Rear tire |
180/65-B16 |
Front brakes |
Double disc. ABS, 4-piston |
Rear brakes |
Single disc. ABS, 4-piston |
Wheels |
Mirror Chrome Slicer Custom Wheel |
Physical measures and capacities |
Dry weight |
414.0 kg (912.7 pounds) |
Weight incl. oil, gas, etc |
431.0 kg (950.2 pounds) |
Power/weight ratio |
0.2464 HP/kg |
Seat height |
720 mm (28.3 inches) If adjustable, lowest setting. |
Overall length |
2600 mm (102.4 inches) |
Ground clearance |
125 mm (4.9 inches) |
Wheelbase |
1625 mm (64.0 inches) |
Fuel capacity |
22.71 litres (6.00 US gallons) |
Oil capacity |
3.80 litres (4.02 US quarts) |
Other specifications |
Color options |
Palladium Silver/Phantom Blue, Black Garnet/Electric Red Pearl, Stardust Silver/Palladium Silver, Spiked Olive/Serpentine Gray Carbon Dust/Electrical Red Pearl, Charcoal Slate/Palladium Silver |
Starter |
Electric |
Light |
High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, 6-speed, low fuel warning, ABS |
Carrying capacity |
Saddle bags, top box |
Comments |
Windshield. Cruise control. Alarm. Infotainment. |
