2015 Harley-Davidson Dyna Street Bob

Stock #20718TWW

332 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2015 Harley-Davidson Dyna Street Bob . You can reach me at or by phone at .
Description
Easily adjust preload with a spanner wrench to suit your suspension to your riding style. The slammed low rear suspension gives you a more laid-back riding position and style. Low-profile, kicked back for profiling down the boulevard and hugging corners.



General information
Model Harley-Davidson Dyna Street Bob
Year 2015
Category Custom / cruiser
Engine and transmission
Displacement 1690.0 ccm (103.12 cubic inches)
Engine type V2, four-stroke
Engine details Air-cooled, Twin Cam 96™
Power 76.4 HP (55.8 kW)) @ 5250 RPM
Torque 130.0 Nm (13.3 kgf-m or 95.9 ft.lbs) @ 3000 RPM
Compression 9.2:1
Bore x stroke 95.3 x 111.3 mm (3.8 x 4.4 inches)
Fuel system Injection. ESPFI
Lubrication system Dry sump
Cooling system Air
Gearbox 6-speed
Transmission type Belt   (final drive)
Clutch Multi-plate with diaphragm spring in oil bath
Driveline Primary chain, 57/38 ratio
Fuel consumption 5.47 litres/100 km (18.3 km/l or 43.00 mpg)
Greenhouse gases 126.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Exhaust system Chrome, staggered, straight-cut shorty exhaust with dual mufflers
Chassis, suspension, brakes and wheels
Rake (fork angle) 29.0°
Trail 119 mm (4.7 inches)
Front tire 100/90-H19
Rear tire 160/70-V17
Front brakes Single disc. Dual-piston. Optional ABS.
Rear brakes Single disc. Single-piston
Wheels Black, Laced Steel
Physical measures and capacities
Dry weight 289.9 kg (639.0 pounds)
Weight incl. oil, gas, etc 304.8 kg (672.0 pounds)
Power/weight ratio 0.2637 HP/kg
Seat height 648 mm (25.5 inches) If adjustable, lowest setting.
Overall length 2357 mm (92.8 inches)
Ground clearance 125 mm (4.9 inches)
Wheelbase 1631 mm (64.2 inches)
Fuel capacity 17.79 litres (4.70 US gallons)
Oil capacity 2.80 litres (2.96 US quarts)
Other specifications
Color options Superial Blue,Hard Candy Quicksilver Flake Deluxe, Black Denim, Vivid Black, Amber Whiskey, H-D1 Factory Customization
Starter Electric
Instruments Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
Light High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system(optional), 6-speed, low fuel warnings
Comments North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
  • Status:
    Pre-Owned
  • Vehicle:
    2015 Harley-Davidson Dyna Street Bob
  • VIN:
    1HD1VAM16FC320718
  • Model Number:
    FXDB
  • Color:
    Black
  • Stock Number:
    20718TWW
  • Title:
    Clear
  • Location:
    Worth Harley-Davidson
  • Warranty:
    As Is

BRAKES

  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

ENGINE

  • Bore (in):
    3.87
  • Bore (mm):
    98.3
  • CAN Liters Per Kilometer (Combined):
    5.5
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    9.6
  • Cooling:
    Air
  • Cylinders:
    2
  • Displacement (cc):
    1689.5
  • Displacement (ci):
    103.1
  • Engine Brand Name:
    Twin Cam 103™
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Premium
  • Fuel Type:
    Gas
  • Starter:
    Electric
  • Stroke (in):
    4.37
  • Stroke (mm):
    111
  • Torque (Ft Lbs):
    98.8
  • Torque (Nm):
    134
  • Torque RPM:
    3000
  • US Miles Per Gallon (Combined):
    43
  • Valve Configuration:
    OHV - Pushrod
  • Valves Per Cylinder:
    2
  • Valves:
    4

EXTERIOR

  • Belt Guard:
    Yes
  • Foot Peg Location:
    Driver
  • Frame:
    Steel
  • Side Cover:
    Yes
  • Stand Type:
    Kick
  • Tank Divider Material:
    Leather

GLASS

  • Folding:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

LIGHTS

  • Type:
    Halogen

SEATS

  • Number Of Seats:
    1
  • Seat Height (in):
    26.8
  • Seat Height (mm):
    680.7
  • Seat Location:
    Driver
  • Seat Material:
    Leather
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

SUSPENSION

  • Front Suspension Size (in):
    1.9
  • Front Suspension Size (mm):
    49
  • Front Suspension Type:
    Telescopic Fork
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    288.9
  • Dry Weight (lbs):
    637
  • Engine Displacement to Weight (cc):
    2.65
  • Fuel Capacity (gal):
    4.7
  • Fuel Capacity (l):
    17.8
  • Ground Clearance (in):
    4.7
  • Ground Clearance (mm):
    119.4
  • Length (ft):
    7.86
  • Length (ft/ft):
    7
  • Length (ft/in):
    10.3
  • Length (in):
    94.3
  • Length (mm):
    2395.2
  • Wet Weight (kg):
    303.9
  • Wet Weight (lbs):
    670
  • Wheelbase (in):
    64.2
  • Wheelbase (mm):
    1630.7

TRANSMISSION

  • Gear Ratio (1):
    9.31
  • Gear Ratio (2):
    6.45
  • Gear Ratio (3):
    4.79
  • Gear Ratio (4):
    3.88
  • Gear Ratio (5):
    3.31
  • Gear Ratio (6):
    2.79
  • Number Of Speeds:
    6
  • Primary Drive (Engine / Transmission):
    Chain
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Brand:
    Six-Speed Cruise Drive®
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    Michelin® Scorcher™ 100/90 R19 57H
  • Front Tire Aspect Ratio:
    90
  • Front Tire Speed Rating:
    H
  • Front Tire Width:
    100
  • Front Wheel Diameter:
    19
  • Rear Tire (Full Spec):
    Michelin® Scorcher™ 160/70 R17 73V
  • Rear Tire Aspect Ratio:
    70
  • Rear Tire Speed Rating:
    W
  • Rear Tire Width:
    160
  • Rear Wheel Diameter:
    17
  • Tire Brand:
    Michelin®
  • Wheels Composition:
    Steel
