2014 Harley-Davidson Touring Ultra Limited

Stock #11327PW
Your Price: $18,981

289 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2014 Harley-Davidson Touring Ultra Limited . You can reach me at or by phone at .

You want a ride that rumbles—not begs for mercy—when you lean on it a little. The Six-Speed Cruise Drive® transmission provides smooth, quiet shifting and reduces engine speed on the highway, so you get a better match between engine turnover and road speed. And the Isolated Drive System makes acceleration flow in a smooth, steady stream from your wrist right down to the pavement.



General information
Model Harley-Davidson Electra Glide Ultra Classic
Year 2014
Category Touring
Engine and transmission
Displacement 1688.0 ccm (103.00 cubic inches)
Engine type V2, four-stroke
Engine details Air-cooled Twin Cam 103™ with Integrated Oil-Cooler
Torque 135.6 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250 RPM
Compression 9.7:1
Bore x stroke 98.4 x 111.3 mm (3.9 x 4.4 inches)
Fuel system Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Cooling system Oil & air
Gearbox 6-speed
Transmission type Belt   (final drive)
Clutch Multi-plate with diaphragm spring in oil bath
Driveline Chain, 34/46 ratio primary drive
Fuel consumption 5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Greenhouse gases 129.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Exhaust system Chrome, 2-1-2 dual exhaust with tapered mufflers
Chassis, suspension, brakes and wheels
Rake (fork angle) 26.0°
Trail 170 mm (6.7 inches)
Front tire 130/80-NW17
Rear tire 180/65-NW16
Front brakes Double disc. 4-piston
Rear brakes Single disc. 2-piston
Wheels Impeller Cast Aluminum
Physical measures and capacities
Dry weight 400.1 kg (882.0 pounds)
Weight incl. oil, gas, etc 413.2 kg (911.0 pounds)
Seat height 693 mm (27.3 inches) If adjustable, lowest setting.
Overall length 2504 mm (98.6 inches)
Ground clearance 130 mm (5.1 inches)
Wheelbase 1613 mm (63.5 inches)
Fuel capacity 22.71 litres (6.00 US gallons)
Oil capacity 3.80 litres (4.02 US quarts)
Other specifications
Color options Sand Pearl/Canyon Brown Pearl, Birch White/Midnight Pearl, Red Sunglo/Blackened Cayenne Sunglo, Big Blue Pearl/Vivid Black,Midnight Pearl, Candy Orange,Blackened Cayenne Sunglo, Vivid Black
Starter Electric
Instruments Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light; cruise control indicator light Tachometer with fuel, voltage, oil pressure and ambient air temperature gauges
Light High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system (optional), 6-speed, low fuel warning, ABS (optional)
Carrying capacity Saddle bags, top box
Comments Windshield
  • Status:
    Pre-Owned
  • Vehicle:
    2014 Harley-Davidson Touring Ultra Limited
  • VIN:
    1HD1KEL1XEB711327
  • Model Number:
    FLHTK
  • Mileage:
    58,112 miles
  • Fuel Type:
    Gasoline
  • Transmission:
    Manual
  • Color:
    MYS RED/CAYENNE W/ PINSTRIP
  • Fuel Economy:
    42 mpg
  • Stock Number:
    11327PW
  • Title:
    Clear
  • Location:
    Worth Harley-Davidson
  • Warranty:
    As Is

AUDIO & COMMUNICATION

  • Brand Name:
    Boom!™ Box 6.5GT
  • Number Of Speakers:
    4

BRAKES

  • Brake Brand Name:
    Brembo®
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

CONVENIENCE

  • Adjustable:
    Yes
  • Engine Immobilizer Brand:
    Digitally Encoded Security System™ (DESS)
  • Heated Hand Grip Location:
    Driver

ENGINE

  • Bore (in):
    3.87
  • Bore (mm):
    98.3
  • CAN Liters Per Kilometer (Combined):
    5.6
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    10.0
  • Cooling:
    Air
  • Cylinders:
    2
  • Displacement (cc):
    1689.5
  • Displacement (ci):
    103.1
  • Engine Brand Name:
    Twin-Cooled™ High-Output Twin Cam 103™
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Premium
  • Fuel Type:
    Gas
  • Starter:
    Electric
  • Stroke (in):
    4.37
  • Stroke (mm):
    111
  • Torque (Ft Lbs):
    105.5
  • Torque (Nm):
    143
  • Torque RPM:
    3750
  • US Miles Per Gallon (Combined):
    42
  • Valve Configuration:
    OHV - Pushrod
  • Valves Per Cylinder:
    2
  • Valves:
    4

EXTERIOR

  • Chassis Protectors:
    Yes
  • Engine Case Guard:
    Yes
  • Floor Board Location:
    Driver and Passenger
  • Frame:
    Steel
  • Saddle Bag Guard:
    Yes
  • Side Cover:
    Yes
  • Stand Type:
    Kick
  • Tank Divider Material:
    Leather

GLASS

  • Folding:
    Yes
  • Height:
    High
  • Windshield Brand:
    Lexan®

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

LIGHTS

  • Type:
    Halogen

SEATS

  • Backrest Location:
    Passenger
  • Backrest Type:
    Fixed
  • Lumbar Adjustment:
    Yes
  • Number Of Seats:
    2
  • Seat Height (in):
    29.1
  • Seat Height (mm):
    739.1
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Leather
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

STORAGE

  • Bag Liner Material:
    Vinyl
  • Location:
    Left and Right Side
  • Number Of Side Cases:
    2
  • Rear Rack Storage Material:
    Hard Vinyl
  • Rear Rack Storage Trim:
    Plain
  • Side Case Material:
    Vinyl

SUSPENSION

  • Air Adjustable:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Suspension Size (in):
    1.9
  • Front Suspension Size (mm):
    49
  • Front Suspension Type:
    Telescopic Fork
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    390.5
  • Dry Weight (lbs):
    861
  • Engine Displacement to Weight (cc):
    1.96
  • Fuel Capacity (gal):
    6
  • Fuel Capacity (l):
    22.7
  • Ground Clearance (in):
    5.3
  • Ground Clearance (mm):
    134.6
  • Length (ft):
    8.53
  • Length (ft/ft):
    8
  • Length (ft/in):
    6.4
  • Length (in):
    102.4
  • Length (mm):
    2601
  • Storage Capacity (cuft):
    4.7
  • Storage Capacity (gal):
    30.2
  • Storage Capacity (l):
    133.1
  • Wet Weight (kg):
    406.4
  • Wet Weight (lbs):
    896
  • Wheelbase (in):
    64
  • Wheelbase (mm):
    1625.6

TRANSMISSION

  • Gear Ratio (1):
    9.593
  • Gear Ratio (2):
    6.65
  • Gear Ratio (3):
    4.938
  • Gear Ratio (4):
    4
  • Gear Ratio (5):
    3.407
  • Gear Ratio (6):
    2.875
  • Number Of Speeds:
    6
  • Primary Drive (Engine / Transmission):
    Chain
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Brand:
    Six-Speed Cruise Drive®
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Chromed:
    Yes
  • Front Tire (Full Spec):
    Dunlop® Multi-Tread™ 130/80 R17 65H
  • Front Tire Aspect Ratio:
    80
  • Front Tire Speed Rating:
    65H
  • Front Tire Width:
    130
  • Front Wheel Diameter:
    17
  • Rear Tire (Full Spec):
    Dunlop® Multi-Tread™ 180/65 R16 81H
  • Rear Tire Aspect Ratio:
    65
  • Rear Tire Speed Rating:
    81H
  • Rear Tire Width:
    180
  • Rear Wheel Diameter:
    16
  • Tire Brand:
    Dunlop®
  • Wheels Composition:
    Aluminum
