2014 Harley-Davidson Dyna Fat Bob

Stock #29081TW
Your Price: $12,016
Contact For Details Hi, my name is and I'm interested in this 2014 Harley-Davidson Dyna Fat Bob . You can reach me at or by phone at .
Description
The 2014 Fat Bob proves there’s no such thing as too much black. From the aluminum triple clamps and battery box cover to the headlight trim ring and rear shock covers, this thick-cut, menacing bad boy is blacked out from top to bottom, nose to tail. Go ahead. Flash some black.



General information
Model Harley-Davidson Dyna Fat Bob
Year 2014
Category Custom / cruiser
Engine and transmission
Displacement 1688.0 ccm (103.00 cubic inches)
Engine type V2, four-stroke
Engine details Air-cooled, Twin Cam 103™
Torque 135.6 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3500 RPM
Compression 9.6:1
Bore x stroke 98.4 x 111.3 mm (3.9 x 4.4 inches)
Fuel system Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Cooling system Air
Gearbox 6-speed
Transmission type Belt   (final drive)
Clutch Multi-plate with diaphragm spring in oil bath
Driveline Primary chain, 34/46 ratio
Fuel consumption 5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Greenhouse gases 129.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Exhaust system Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
Chassis, suspension, brakes and wheels
Rake (fork angle) 29.0°
Trail 124 mm (4.9 inches)
Front tire 130/90-B16
Rear tire 180/70-B16
Front brakes Double disc. 4-piston fixed
Rear brakes Single disc. 2-piston torque-free floating
Wheels Machined, Aluminum Slotted Disc
Physical measures and capacities
Dry weight 305.3 kg (673.0 pounds)
Weight incl. oil, gas, etc 320.2 kg (706.0 pounds)
Seat height 663 mm (26.1 inches) If adjustable, lowest setting.
Overall length 2329 mm (91.7 inches)
Ground clearance 124 mm (4.9 inches)
Wheelbase 1621 mm (63.8 inches)
Fuel capacity 18.93 litres (5.00 US gallons)
Oil capacity 2.80 litres (2.96 US quarts)
Other specifications
Color options Sand Cammo Denim, Black Denim,Amber Whiskey, Vivid Black
Starter Electric
Instruments Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
Light High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system(optional), 6-speed, low fuel warnings
Comments North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
  • Status:
    Pre-Owned
  • Vehicle:
    2014 Harley-Davidson Dyna Fat Bob
  • VIN:
    1HD1GYM16EC329081
  • Model Number:
    FXDF
  • Mileage:
    8,940 miles
  • Color:
    Amber Whiskey
  • Stock Number:
    29081TW
  • Title:
    Clear
  • Location:
    Worth Harley-Davidson
  • Warranty:
    As Is

BRAKES

  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

ENGINE

  • Bore (in):
    3.87
  • Bore (mm):
    98.3
  • CAN Liters Per Kilometer (Combined):
    5.6
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    9.6
  • Cooling:
    Air
  • Cylinders:
    2
  • Displacement (cc):
    1689.5
  • Displacement (ci):
    103.1
  • Engine Brand Name:
    Twin Cam 103™
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Premium
  • Fuel Type:
    Gas
  • Starter:
    Electric
  • Stroke (in):
    4.37
  • Stroke (mm):
    111
  • Torque (Ft Lbs):
    98.8
  • Torque (Nm):
    134
  • Torque RPM:
    3500
  • US Miles Per Gallon (Combined):
    42
  • Valve Configuration:
    OHV - Pushrod
  • Valves Per Cylinder:
    2
  • Valves:
    4

EXTERIOR

  • Belt Guard:
    Yes
  • Foot Peg Location:
    Driver and Passenger
  • Frame:
    Steel
  • Side Cover:
    Yes
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

LIGHTS

  • Type:
    Halogen

SEATS

  • Number Of Seats:
    2
  • Seat Height (in):
    27.2
  • Seat Height (mm):
    690.9
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Leather
  • Seat Type:
    Two-Piece

STEERING

  • Steering Control:
    Handlebar

SUSPENSION

  • Front Suspension Size (in):
    1.9
  • Front Suspension Size (mm):
    49
  • Front Suspension Type:
    Telescopic Fork
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    305.3
  • Dry Weight (lbs):
    673
  • Engine Displacement to Weight (cc):
    2.51
  • Fuel Capacity (gal):
    5
  • Fuel Capacity (l):
    18.9
  • Ground Clearance (in):
    4.9
  • Ground Clearance (mm):
    124.5
  • Length (ft):
    7.88
  • Length (ft/ft):
    7
  • Length (ft/in):
    10.5
  • Length (in):
    94.5
  • Length (mm):
    2400.3
  • Wet Weight (kg):
    320.2
  • Wet Weight (lbs):
    706
  • Wheelbase (in):
    63.8
  • Wheelbase (mm):
    1620.5

TRANSMISSION

  • Gear Ratio (1):
    9.31
  • Gear Ratio (2):
    6.45
  • Gear Ratio (3):
    4.79
  • Gear Ratio (4):
    3.88
  • Gear Ratio (5):
    3.31
  • Gear Ratio (6):
    2.79
  • Number Of Speeds:
    6
  • Primary Drive (Engine / Transmission):
    Chain
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Brand:
    Six-Speed Cruise Drive®
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    Michelin® Scorcher™ 130/90 R16 67H
  • Front Tire Aspect Ratio:
    90
  • Front Tire Speed Rating:
    H
  • Front Tire Width:
    130
  • Front Wheel Diameter:
    16
  • Rear Tire (Full Spec):
    Michelin® Scorcher™ 180/70 R16 77H
  • Rear Tire Aspect Ratio:
    70
  • Rear Tire Speed Rating:
    W
  • Rear Tire Width:
    180
  • Rear Wheel Diameter:
    16
  • Tire Brand:
    Michelin®
  • Wheels Composition:
    Aluminum
