2009 Harley-Davidson Road King Classic

Stock #92392TW
Your Price: $12,997

283 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2009 Harley-Davidson Road King Classic . You can reach me at or by phone at .
Description

Rolling nostalgia you can ride over the horizon, the Road King Classic incorporates styling elements from the past in a touring motorcycle with modern technology.



General information
Model Harley-Davidson FLHRC Road King Classic
Year 2009
Category Touring
Engine and transmission
Displacement 1584.0 ccm (96.66 cubic inches)
Engine type V2, four-stroke
Torque 131.0 Nm (13.4 kgf-m or 96.6 ft.lbs) @ 3500 RPM
Compression 9.2:1
Bore x stroke 95.3 x 111.1 mm (3.8 x 4.4 inches)
Fuel system Injection
Cooling system Air
Gearbox 6-speed
Transmission type Belt   (final drive)
Exhaust system Two-into-One-into-Two chrome exhaust
Chassis, suspension, brakes and wheels
Frame type New mild steel, single spar rigid backbone with
Rake (fork angle) 26.0°
Trail 173 mm (6.8 inches)
Front suspension 41.3mm telescopic
Front wheel travel 117 mm (4.6 inches)
Rear suspension Handling
Rear wheel travel 76 mm (3.0 inches)
Front tire 130/90-60
Rear tire 180/65-16
Front brakes Double disc. 4-piston, ABS
Diameter 300 mm (11.8 inches)
Rear brakes Single disc. 4-piston, ABS
Diameter 300 mm (11.8 inches)
Physical measures and capacities
Dry weight 355.0 kg (782.6 pounds)
Seat height 715 mm (28.1 inches) If adjustable, lowest setting.
Overall length 2400 mm (94.5 inches)
Ground clearance 145 mm (5.7 inches)
Wheelbase 1625 mm (64.0 inches)
Fuel capacity 22.70 litres (6.00 US gallons)
Other specifications
Color options Vivid Black, Pewter Pearl, Flame Blue Pearl, White Gold Pearl and Pewter Pearl, Deep Turquoise and Antique White; Red Hot Sunglo and Smokey Gold
Starter Electric
Comments Black powder-coated engine with chrome treatment covers; Chrome, nostalgic fuel tank console; Clear-lens reflector-optics headlamp; Full-length height adjustable rider footboards; Full-length height adjustable passenger footboards; New redesigned rider footboard supports for increased lean angle; Stainless steel, “buffalo” handlebars; One-piece, two-up Road King® classic seat; Clear, large Lexan® quick-release detachable windshield; Leather-wrapped hard bags; Cruise control;
Modifications compared to previous model Retuned front and rear suspension for enhanced handling.
  • Status:
    Pre-Owned
  • Vehicle:
    2009 Harley-Davidson Road King Classic
  • VIN:
    1HD1FR4159Y692392
  • Model Number:
    FLHRC
  • Mileage:
    33,882 miles
  • Color:
    BLACK W/PINSTRIPE
  • Stock Number:
    92392TW
  • Title:
    Clear
  • Location:
    Worth Harley-Davidson
  • Warranty:
    As Is

BRAKES

  • Brake Brand Name:
    Brembo®
  • Front Brake Diameter (in):
    11.5
  • Front Brake Diameter (mm):
    292.1
  • Front Brake Type:
    Dual Disc
  • Rear Brake Diameter (in):
    11.5
  • Rear Brake Diameter (mm):
    292.1
  • Rear Brake Type:
    Disc

ENGINE

  • Bore (in):
    3.75
  • Bore (mm):
    95.3
  • CAN Liters Per Kilometer (City):
    6.7
  • CAN Liters Per Kilometer (Hwy):
    4.4
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    9.2
  • Cooling:
    Air
  • Cylinders:
    2
  • Displacement (cc):
    1584
  • Displacement (ci):
    96
  • Engine Brand Name:
    Twin Cam 96™
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Premium
  • Fuel Type:
    Gas
  • Starter:
    Electric
  • Stroke (in):
    4.38
  • Stroke (mm):
    111.3
  • Torque (Ft Lbs):
    92.6
  • Torque (Nm):
    125.6
  • Torque RPM:
    3500
  • US Miles Per Gallon (City):
    35
  • US Miles Per Gallon (Hwy):
    54
  • Valve Configuration:
    OHV - Pushrod
  • Valves Per Cylinder:
    2
  • Valves:
    4

EXTERIOR

  • Chassis Protectors:
    Yes
  • Engine Case Guard:
    Yes
  • Floor Board Location:
    Driver and Passenger
  • Fork Guards:
    Yes
  • Frame:
    Steel
  • Saddle Bag Guard:
    Yes
  • Side Cover:
    Yes
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes
  • Height:
    High
  • Windshield Brand:
    Lexan®

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

LIGHTS

  • Type:
    Halogen

SEATS

  • Number Of Seats:
    2
  • Seat Height (in):
    26.9
  • Seat Height (mm):
    683.3
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Leather
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

STORAGE

  • Location:
    Left and Right Side
  • Number Of Side Cases:
    2
  • Side Case Material:
    Leather

SUSPENSION

  • Air Adjustable:
    Yes
  • Front Suspension Type:
    Telescopic Fork
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    350.6
  • Dry Weight (lbs):
    773
  • Engine Displacement to Weight (cc):
    2.05
  • Fuel Capacity (gal):
    6
  • Fuel Capacity (l):
    22.7
  • Ground Clearance (in):
    5.1
  • Ground Clearance (mm):
    129.5
  • Length (ft):
    7.85
  • Length (ft/ft):
    7
  • Length (ft/in):
    10.2
  • Length (in):
    94.2
  • Length (mm):
    2392.7
  • Wet Weight (kg):
    367.4
  • Wet Weight (lbs):
    810
  • Wheelbase (in):
    63.5
  • Wheelbase (mm):
    1612.9

TRANSMISSION

  • Gear Ratio (1):
    9.59
  • Gear Ratio (2):
    6.65
  • Gear Ratio (3):
    4.94
  • Gear Ratio (4):
    4
  • Gear Ratio (5):
    3.41
  • Gear Ratio (6):
    2.88
  • Number Of Speeds:
    6
  • Primary Drive (Engine / Transmission):
    Chain
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Chromed:
    Yes
  • Front Tire (Full Spec):
    Dunlop® 130/80 R17 65H
  • Front Tire Aspect Ratio:
    80
  • Front Tire Speed Rating:
    65H
  • Front Tire Width:
    130
  • Front Wheel Diameter:
    17
  • Rear Tire (Full Spec):
    Dunlop® 180/65 R16 81H
  • Rear Tire Aspect Ratio:
    65
  • Rear Tire Speed Rating:
    81H
  • Rear Tire Width:
    180
  • Rear Wheel Diameter:
    16
  • Tire Brand:
    Dunlop®
  • Wheels Composition:
    Steel
