2005 Harley-Davidson Heritage Softail Classic

Stock #88242TW
Your Price: $9,981

268 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2005 Harley-Davidson Heritage Softail Classic . You can reach me at or by phone at .
Description

Twist the throttle of the timeless Heritage Softail® Classic and you are propelled forward and back all at once. Generously studded leather bags. Massive fenders with chrome accents. Wide tires on wire-laced wheels. Detachable king-size windshield. Low two-up seat with backrest. Giant chrome headlight and passing lamps. An eyeful of all these goodies and it’s easy to see the inspiration for this bike was the early dressers.



General information
Model Harley-Davidson FLSTCI Heritage Softail Classic
Year 2005
Category Custom / cruiser
Engine and transmission
Displacement 1449.0 ccm (88.42 cubic inches)
Engine type V2, four-stroke
Power 67.0 HP (48.9 kW))
Torque 102.0 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 3500 RPM
Compression 8.8:1
Bore x stroke 95.3 x 101.6 mm (3.8 x 4.0 inches)
Valves per cylinder 2
Fuel system Injection. Electronic Sequential Port Fuel Injection (ESPFI )
Fuel control Double Overhead Cams/Twin Cam (DOHC)
Ignition Single-fire, non-wasted, map-controlled spark ignition
Lubrication system Dry sump, internally mounted, crank driven gerotor
Cooling system Air
Gearbox 5-speed
Transmission type Belt   (final drive)
Clutch Multi-plate clutch with diaphragm spring in oil bath
Chassis, suspension, brakes and wheels
Rake (fork angle) 32.0°
Trail 147 mm (5.8 inches)
Front suspension 41.3 mm telescopic forks, with beer can covers
Rear suspension Dual down-tubes, Swing Arm Triangular hard tail style
Rear tire 150/80-B16
Front brakes Single disc. Four-piston calipers.
Diameter 292 mm (11.5 inches)
Rear brakes Single disc. Four-piston calipers.
Diameter 292 mm (11.5 inches)
Physical measures and capacities
Dry weight 322.0 kg (709.9 pounds)
Weight incl. oil, gas, etc 337.0 kg (743.0 pounds)
Power/weight ratio 0.2081 HP/kg
Seat height 648 mm (25.5 inches) If adjustable, lowest setting.
Overall length 2391 mm (94.1 inches)
Ground clearance 130 mm (5.1 inches)
Wheelbase 1630 mm (64.2 inches)
Fuel capacity 18.90 litres (4.99 US gallons)
Other specifications
Color options Vivid black, brilliant silver pearl, black cherry pearl, lava red sunglo, glacier white pearl, rich sunglo blue, two-tone rich sunglo blue and chopper blue pearl, two-tone black cherry pearl and black pearl, two-tone sierra red pearl and brilliant silver
Starter Electric
  • Status:
    Pre-Owned
  • Vehicle:
    2005 Harley-Davidson Heritage Softail Classic
  • VIN:
    1HD1BWB125Y088242
  • Model Number:
    FLSTC
  • Mileage:
    36,728 miles
  • Color:
    2/T ORANGE
  • Stock Number:
    88242TW
  • Title:
    Clear
  • Location:
    Worth Harley-Davidson
  • Warranty:
    As Is

BRAKES

  • Front Brake Diameter (in):
    11.5
  • Front Brake Diameter (mm):
    292.1
  • Front Brake Type:
    Disc
  • Rear Brake Diameter (in):
    11.5
  • Rear Brake Diameter (mm):
    292.1
  • Rear Brake Type:
    Disc

ENGINE

  • Bore (in):
    3.75
  • Bore (mm):
    95.3
  • CAN Liters Per Kilometer (City):
    5.7
  • CAN Liters Per Kilometer (Hwy):
    4.9
  • Carburetion Type:
    Carburetor
  • Carburetor Size (mm):
    40
  • Carburetor:
    Yes
  • Compression Ratio:
    8.9
  • Cooling:
    Air
  • Cylinders:
    2
  • Displacement (cc):
    1442.1
  • Displacement (ci):
    88
  • Engine Brand Name:
    Twin Cam 88B®
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Requirements:
    Premium
  • Fuel Type:
    Gas
  • Number Of Carburetors:
    1
  • Starter:
    Electric
  • Stroke (in):
    4
  • Stroke (mm):
    101.6
  • Torque (Ft Lbs):
    85
  • Torque (Nm):
    115.2
  • Torque RPM:
    3000
  • US Miles Per Gallon (City):
    41
  • US Miles Per Gallon (Hwy):
    48
  • Valve Configuration:
    OHV - Pushrod
  • Valves Per Cylinder:
    2
  • Valves:
    4

EXTERIOR

  • Belt Guard:
    Yes
  • Floor Board Location:
    Driver
  • Foot Peg Location:
    Passenger
  • Frame:
    Steel
  • Side Cover:
    Yes
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes
  • Height:
    High
  • Windshield Brand:
    Lexan®

LIGHTS

  • Type:
    Halogen

SEATS

  • Backrest Location:
    Passenger
  • Backrest Type:
    Fixed
  • Number Of Seats:
    2
  • Seat Height (in):
    25.5
  • Seat Height (mm):
    647.7
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Leather
  • Seat Type:
    Two-Piece

STEERING

  • Steering Control:
    Handlebar

STORAGE

  • Location:
    Left and Right Side
  • Number Of Saddle Bags:
    2
  • Saddle Bag Material:
    Leather
  • Saddle Bag Trim:
    Studded

SUSPENSION

  • Front Suspension Type:
    Telescopic Fork
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    315.7
  • Dry Weight (lbs):
    696
  • Engine Displacement to Weight (cc):
    2.07
  • Fuel Capacity (gal):
    5
  • Fuel Capacity (l):
    18.9
  • Ground Clearance (in):
    5.1
  • Ground Clearance (mm):
    129.5
  • Length (ft):
    7.88
  • Length (ft/ft):
    7
  • Length (ft/in):
    10.5
  • Length (in):
    94.5
  • Length (mm):
    2400.3
  • Wheelbase (in):
    64.5
  • Wheelbase (mm):
    1638.3

TRANSMISSION

  • Gear Ratio (1):
    10.11
  • Gear Ratio (2):
    6.96
  • Gear Ratio (3):
    4.95
  • Gear Ratio (4):
    3.86
  • Gear Ratio (5):
    3.15
  • Number Of Speeds:
    5
  • Primary Drive (Engine / Transmission):
    Chain
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    Dunlop MT90B16 72H
  • Front Tire Aspect Ratio:
    90
  • Front Tire Speed Rating:
    72H
  • Front Wheel Diameter:
    16
  • Rear Tire (Full Spec):
    Dunlop 150/80 R16 71H
  • Rear Tire Aspect Ratio:
    80
  • Rear Tire Speed Rating:
    71H
  • Rear Tire Width:
    150
  • Rear Wheel Diameter:
    16
  • Tire Brand:
    Dunlop®
  • Wheels Composition:
    Steel
